Spring

• Spring JAVA 버전은 17이 제일 깔끔함

• project Facets > Java (Version 1.6) > 11로 변경

  • properties → java compiler에서 11로 바꾸면 됨

• 스프링 두 가지 XML 파일

  1. 전체 설정 파일

  2. 서블릿 파일 : <WEB> 설정

설치 (아래 링크 참고)

http://thedata.kr/down/spring4/01.spring-setup.html

회원가입 & 로그인

1. 패키지 새로 생성 : hello2 만들기



2. Version 설정

   • Package > Properties

     • java compiler



     • Project Facets : Dynamic Web Module / Java 설정



3. pom.xml 설정

   • hello.pom을 복사해서 hello2.pom에 갖다 붙여넣기

     • mybatis, lombok, jstl, springjdbc, mysql, DB tool 등

4. web.xml 설정

   • Tomcat이 제일 먼저 읽는 파일로 한글 필터 작업 해줘야 함

     <filter>
     	<filter-name>encodingFilter</filter-name>
     	<filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class>
     	<init-param>
     		<param-name>encoding</param-name>
     		<param-value>UTF-8</param-value>
     	</init-param>
     	<init-param>
     		<param-name>forceEncoding</param-name>
     		<param-value>true</param-value>
     	</init-param>
     </filter>

     <filter-mapping>
     	<filter-name>encodingFilter</filter-name>
     	<url-pattern>/*</url-pattern>
     </filter-mapping>

5. root-context.xml 파일에 DB 설정

   • bean : spring이 new 해서 만든 것 (= class 생성)

   <bean
   	id="dataSource"
   	class="org.apache.commons.dbcp2.BasicDataSource"
   	destroy-method="close">
   	<property name="driverClassName" value="com.mysql.cj.jdbc.Driver" />
   	<property name="url" value="jdbc:mysql://localhost:3306/kdigital?serverTimezone=UTC" />
   	<property name="username" value="root" />
   	<property name="password" value="rpass"></property>
   </bean>

   <bean
   	id="sqlSessionFactory"
   	class="org.mybatis.spring.SqlSessionFactoryBean">
   	<property name="dataSource" ref="dataSource"></property>
   	<property name="configLocation" value="classpath:/sqlmap/mybatis-config.xml"></property>
   </bean>
   <bean id="sqlSessionTemplate" class="org.mybatis.spring.SqlSessionTemplate">
   	<constructor-arg index="0" ref="sqlSessionFactory"></constructor-arg>
   </bean>

6. 폴더 생성

   • views 하위에 member 폴더 생성



   • DB에 테이블이 만들어져야 DTO가 만들 수 있음

     CREATE TABLE `member` (
       `id` varchar(50) NOT NULL,
       `pw` varchar(50) NOT NULL,
       `name` varchar(50) NOT NULL,
       `age` int NOT NULL DEFAULT '0',
       PRIMARY KEY (`id`)
     ) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci;

7. DTO 생성 후 @Data 생성 (lombok)



8. Controller에 스프링 설정



9. 파일 준비

   • MemberController

     package com.spring.hello2.controller;

     import org.springframework.beans.factory.annotation.Autowired;
     import org.springframework.stereotype.Controller;

     import com.spring.hello2.service.MemberService;

     @Controller
     public class MemberController {

     	MemberService service;

     	@Autowired
     	public MemberController() {
     		System.out.println("MemberController()");
       		this.service = service;
       	}
     }

   • MemberDAO

     package com.spring.hello2.dao;

     import org.mybatis.spring.SqlSessionTemplate;
     import org.springframework.beans.factory.annotation.Autowired;
     import org.springframework.stereotype.Repository;

     @Repository
     public class MemberDAO {

     	SqlSessionTemplate sqlSession; //root-context.xml에서 bean으로 생성함

     	@Autowired
     	public MemberDAO() {
     		System.out.println("MemberDAO()");
     		this.sqlSession = sqlSession;
     	}
     }

   • MemberDTO

     package com.spring.hello2.dto;

     import lombok.Data;

     @Data
     public class MemberDTO {
     	String id;
     	String pw;
     	String name;
     	int age;
     }

   • MemberService

     package com.spring.hello2.service;

     public interface MemberService { }

   • MemberService.impl

     package com.spring.hello2.service.impl;

     import org.springframework.stereotype.Service;

     import com.spring.hello2.dao.MemberDAO;
     import com.spring.hello2.service.MemberService;

     @Service
     public class MemberServiceImpl implements MemberService {

     	MemberDAO dao;

     	public MemberServiceImpl() {
     		System.out.println("MemberServiceImpl()");
     		this.dao = dao;
     	}
     }

     => 이대로 실행하면 mapper 파일이 없어 오류가 나므로 mapper 파일 생성해줘야 함



   • mybatis-config

     <?xml version="1.0" encoding="UTF-8" ?>
     <!DOCTYPE configuration
       PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
       "https://mybatis.org/dtd/mybatis-3-config.dtd">
     <configuration>

       <mappers>
         <mapper resource="/sqlmap/mapper/member-mapper.xml"/>
       </mappers>
     </configuration>

   • member-mapper.xml

     <?xml version="1.0" encoding="UTF-8" ?>
     <!DOCTYPE mapper
       PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
       "https://mybatis.org/dtd/mybatis-3-mapper.dtd">
     <mapper namespace="member">
     	<insert id="insert" parameterType="MemberDTO">
     	<![CDATA[
     		insert into book(id, pw, name, age) values (#{id}, #{pw}, #{name}, #{age})
     	]]>
     	</insert>

     	<update id="update" parameterType="MemberDTO">
           <![CDATA[
              update member set pw = #{pw}, name = #{name}, age = #{age}
              where id = #{id}
           ]]>
     	</update>

     	<delete id="delete" parameterType="MemberDTO">
     	<![CDATA[
     		delete from member where id = #{id}
     	]]>
     	</delete>

     	<select id="list" resultType="MemberDTO">
     	<![CDATA[
     		select id, pw, name, age
     		from member
     		where 1 = 1
     	]]>
     	</select>

     	<select id="detail" parameterType="MemberDTO" resultType="MemberDTO">
     	<![CDATA[
     		select id, pw, name, age
     		from member
     		where id = #{id}
     	]]>
     	</select>

     </mapper>

10. home.jsp 경로 설정

    <%@ taglib uri="http://java.sun.com/jsp/jstl/core" prefix="c" %>
    <%@ page session="false" %>
    <html>
    <head>
    	<title>Home</title>
    </head>
    <body>
    <h1>
    	Member
    </h1>
    <ul>
    <li><a href="member/list">List</a></li>
    <li><a href="member/create">Create</a></li>
    <li><a href="member/login">Login</a></li>
    <li><a href="member/logout">Logout</a></li>
    </ul>
    </body>
    </html>
