Spring JAVA 버전은 17이 제일 깔끔함
project Facets > Java (Version 1.6) > 11로 변경
properties → java compiler에서 11로 바꾸면 됨
스프링 두 가지 XML 파일
전체 설정 파일
서블릿 파일 : <WEB> 설정

설치 (아래 링크 참고)

http://thedata.kr/down/spring4/01.spring-setup.html

회원가입 & 로그인

패키지 새로 생성 : hello2 만들기

Version 설정
- Package > Properties
  - java compiler
  - Project Facets : Dynamic Web Module / Java 설정
pom.xml 설정
- hello.pom을 복사해서 hello2.pom에 갖다 붙여넣기
  - mybatis, lombok, jstl, springjdbc, mysql, DB tool 등

web.xml 설정

Tomcat이 제일 먼저 읽는 파일로 한글 필터 작업 해줘야 함

<filter>
	<filter-name>encodingFilter</filter-name>
	<filter-class>org.springframework.web.filter.CharacterEncodingFilter</filter-class>
	<init-param>
		<param-name>encoding</param-name>
		<param-value>UTF-8</param-value>
	</init-param>
	<init-param>
		<param-name>forceEncoding</param-name>
		<param-value>true</param-value>
	</init-param>
</filter>

<filter-mapping>
	<filter-name>encodingFilter</filter-name>
	<url-pattern>/*</url-pattern>
</filter-mapping>

root-context.xml 파일에 DB 설정

bean : spring이 new 해서 만든 것 (= class 생성)

<bean
	id="dataSource"
	class="org.apache.commons.dbcp2.BasicDataSource"
	destroy-method="close">
	<property name="driverClassName" value="com.mysql.cj.jdbc.Driver" />
	<property name="url" value="jdbc:mysql://localhost:3306/kdigital?serverTimezone=UTC" />
	<property name="username" value="root" />
	<property name="password" value="rpass"></property>
</bean>

<bean
	id="sqlSessionFactory"
	class="org.mybatis.spring.SqlSessionFactoryBean">
	<property name="dataSource" ref="dataSource"></property>
	<property name="configLocation" value="classpath:/sqlmap/mybatis-config.xml"></property>
</bean>
<bean id="sqlSessionTemplate" class="org.mybatis.spring.SqlSessionTemplate">
	<constructor-arg index="0" ref="sqlSessionFactory"></constructor-arg>
</bean>

폴더 생성

views 하위에 member 폴더 생성

DB에 테이블이 만들어져야 DTO가 만들 수 있음

CREATE TABLE `member` (
  `id` varchar(50) NOT NULL,
  `pw` varchar(50) NOT NULL,
  `name` varchar(50) NOT NULL,
  `age` int NOT NULL DEFAULT '0',
  PRIMARY KEY (`id`)
) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COLLATE=utf8mb4_0900_ai_ci;

DTO 생성 후 @Data 생성 (lombok)
Controller에 스프링 설정

파일 준비

MemberController

package com.spring.hello2.controller;

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;

import com.spring.hello2.service.MemberService;

@Controller
public class MemberController {

	MemberService service;

	@Autowired
	public MemberController() {
		System.out.println("MemberController()");
  		this.service = service;
  	}
}

MemberDAO

package com.spring.hello2.dao;

import org.mybatis.spring.SqlSessionTemplate;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Repository;

@Repository
public class MemberDAO {

	SqlSessionTemplate sqlSession; //root-context.xml에서 bean으로 생성함

	@Autowired
	public MemberDAO() {
		System.out.println("MemberDAO()");
		this.sqlSession = sqlSession;
	}
}

MemberDTO

package com.spring.hello2.dto;

import lombok.Data;

@Data
public class MemberDTO {
	String id;
	String pw;
	String name;
	int age;
}

MemberService

package com.spring.hello2.service;

public interface MemberService { }

MemberService.impl

package com.spring.hello2.service.impl;

import org.springframework.stereotype.Service;

import com.spring.hello2.dao.MemberDAO;
import com.spring.hello2.service.MemberService;

@Service
public class MemberServiceImpl implements MemberService {

	MemberDAO dao;

	public MemberServiceImpl() {
		System.out.println("MemberServiceImpl()");
		this.dao = dao;
	}
}

=> 이대로 실행하면 mapper 파일이 없어 오류가 나므로 mapper 파일 생성해줘야 함

mybatis-config

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE configuration
  PUBLIC "-//mybatis.org//DTD Config 3.0//EN"
  "https://mybatis.org/dtd/mybatis-3-config.dtd">
<configuration>

  <mappers>
    <mapper resource="/sqlmap/mapper/member-mapper.xml"/>
  </mappers>
</configuration>

member-mapper.xml

<?xml version="1.0" encoding="UTF-8" ?>
<!DOCTYPE mapper
  PUBLIC "-//mybatis.org//DTD Mapper 3.0//EN"
  "https://mybatis.org/dtd/mybatis-3-mapper.dtd">
<mapper namespace="member">
	<insert id="insert" parameterType="MemberDTO">
	<![CDATA[
		insert into book(id, pw, name, age) values (#{id}, #{pw}, #{name}, #{age})
	]]>
	</insert>

	<update id="update" parameterType="MemberDTO">
      <![CDATA[
         update member set pw = #{pw}, name = #{name}, age = #{age}
         where id = #{id}
      ]]>
	</update>

	<delete id="delete" parameterType="MemberDTO">
	<![CDATA[
		delete from member where id = #{id}
	]]>
	</delete>

	<select id="list" resultType="MemberDTO">
	<![CDATA[
		select id, pw, name, age
		from member
		where 1 = 1
	]]>
	</select>

	<select id="detail" parameterType="MemberDTO" resultType="MemberDTO">
	<![CDATA[
		select id, pw, name, age
		from member
		where id = #{id}
	]]>
	</select>

</mapper>

home.jsp 경로 설정

<%@ taglib uri="http://java.sun.com/jsp/jstl/core" prefix="c" %>
<%@ page session="false" %>
<html>
<head>
	<title>Home</title>
</head>
<body>
<h1>
	Member
</h1>
<ul>
<li><a href="member/list">List</a></li>
<li><a href="member/create">Create</a></li>
<li><a href="member/login">Login</a></li>
<li><a href="member/logout">Logout</a></li>
</ul>
</body>
</html>
